Zeiss Thermal DTI 1/25
Zeiss

Zeiss Thermal DTI 1/25

527005

$2,649.00
/
Tax included. Shipping calculated at checkout.

Incl. GSTFree standard post on orders over $700

  • In store:
  • In stock at supplier, ships in about 5 business days5
  • Special order, allow 5+ days
  • Out of stock at supplier, enquire with store

Tell us how many you need and we'll check every supplier and give you a straight answer on availability, price and lead time.

No order is placed and nothing is charged; a staff member replies personally.

One email when it's back. You'll also be added to our newsletter — unsubscribe any time.

Indent order. Ordered in for you from our supplier and paid in full (100%) at order. The expected date is the supplier's estimate and can move; we'll email you if it changes. Indent orders can't be returned for change of mind, and a cancellation is refunded less any costs already incurred. See our Payment, Deposits and Orders and Refunds policies. Your consumer guarantee rights are not affected.

The ZEISS DTI 1 is the compact, lightweight entry model in the ZEISS DTI family, weighing 360 g with a 384 × 288 sensor.

The ZEISS DTI 1/25 pairs a 384 × 288 thermal sensor with a 25 mm, F1.0 lens, rated by ZEISS to detect at up to 1,300 m. Battery life is quoted at 6.5 h and it is IP65 rated.

At a Glance

384 × 288 @ 12 µmThermal sensor ≤35 mKSensitivity (NETD) 25 mm, F1.0Objective lens
1,300 mDetection range 360 gWeight

Key Features

  • 360 g compact body – 175 × 57 × 59 mm with a 1/4-inch tripod thread underneath.
  • 384 × 288 sensor, NETD ≤ 35 mK – 12 µm pitch at 50 Hz behind a 25 mm F1.0 lens: 1,300 m detection range and 18 m field at 100 m (DTI 1/25).
  • HD LCOS display, 1,280 × 960 – 2.5x optical magnification with digital zoom to 4.0x.
  • Transition Zoom and eight colour modes – ZEISS's Transition Zoom gives a continuous zoom effect; colour modes include a Detection Mode that makes heat sources easier to find and modes that cut screen glare.
  • Photo, video and Wi-Fi streaming – 8 GB internal memory; WLAN connection to the ZEISS Hunting App; USB charging and data transfer.
  • 6.5 h battery life – permanently installed Li-ion battery; IP65; operates -10 to +50 °C.

Best For

  • A compact spotter that rides on every hunt
  • Short-to-medium range scanning in forest and scrub
  • A first thermal from a premium brand

Specifications

Detector
Resolution 384 × 288
Pixel pitch 12 µm
Frame rate 50 Hz
Sensitivity (NETD) ≤35 mK
Optics
Objective lens 25 mm, F1.0
Linear field of view 18 m
Field of view 11° × 8°
Base magnification 2.5
Digital zoom 1.0 × – 4.0 ×
Display
Display resolution 1,280 × 960
Screen LCOS
Range Performance
Detection range 1,300 m
Recording & Connectivity
Recording Video, photo
Storage 8 GB
Wi-Fi 2.4 GHz
App ZEISS Hunting App
Power
Battery Lithium-ion
Battery life 6.5 h
External power 5 V / 2A (USB)
Physical & Environmental
Water / dust protection IP65
Operating temperature -10 to +50 °C
Dimensions (L × W × H) 175 × 57 × 59 mm
Weight 360 g

In the Box

  • Thermal imaging camera
  • Neoprene strap
  • Carrying case incl. shoulder strap
  • USB cable
  • Optics cleaning cloth

Watch It in Action

Frequently Asked Questions

How far can the ZEISS DTI 1/25 see?

ZEISS rates detection at 1,300 m — the distance at which a heat source shows on screen. Recognising what an animal is happens closer than that, and rain, fog and high humidity all shorten thermal range.

How long does the battery last?

ZEISS quotes 6.5 h. Battery: Lithium-ion.

Does it connect to a phone?

Yes. It connects over Wi-Fi to the ZEISS Hunting App app for live view, photo and video download and firmware updates.

Supported in Australia through ZEISS's local distributor for warranty and service. Not sure which model suits your country or budget? Get in touch and we'll help you choose.
